ZHEJIANG XINYI INTELLIGENT DRIVE TECHNOLOGY CO.,LTD

Miniature Linear Actuator For Electric Wheelchair
Miniature Linear Actuator For Electric Wheelchair
Miniature Linear Actuator For Electric Wheelchair
Miniature Linear Actuator For Electric Wheelchair

Miniature Linear Actuator For Electric Wheelchair

Payment Type: L/C,T/T,D/P
Incoterm: FOB,CFR,CIF
Min. Order: 1 Piece/Pieces
Delivery Time: 7 Days

Contact Now Add to Basket

Basic Info

    Model No.: XYA2

    Certification: FCC, CCC, SGS, RoHS, ISO, CE

    IP Rating: IP54

    Limit Switch: Built-in

    Voltage: 24VDC

    Standard Stroke: 500mm

    Max Thrust: 6000N

Additional Info

    Productivity: 400,000pieces

    Brand: Xinyi

    Transportation: Ocean,Land,Air

    Place of Origin: Shaoxing,Zhejiang,China

    Certificate: ISO9001

    Port: Ningbo Port,Shanghai Port

Product Description

Product Description:

Miniature GEAR MOTOR For Electric Wheelchair



ZHJIANG XINYI INTELLIGENT DRIVING TECHNOLOGY had always been devoted to the research and development of the Linear Actuator For Electric Wheelchair

Medical Care Motor to provide the user with movement. Sitting in the same position can get tiring for wheelchair users. Changing positions in a static wheelchair can make the person uncomfortable and could lead to pressure sores. Integrating a wheelchair with DC MOTOR can help provide movement to different parts of the wheelchair, which will allow users to adjust their positions.

ZHJIANG XINYI INTELLIGENT DRIVING TECHNOLOGY offers DC Motor For Wheelchair Lift These specialized ELECTRIC MOTOR offer the following benefits:

· Quality raw materials engineered to perfection

· Reliability and safety

· Durable products

· Small in size

· Accurate vertical and horizontal adjustment

· Smooth and quiet operation

· Increased freedom of design

· Reduced maintenance due to use of high quality products



Technical data:

Input voltage:12VDC/24VDC/36VDC

Max.load:Thrust 6000N,Pull 4000N

Speed: (5mm/s 6000N) (10mm/s 3000N) (20mm/s 2000N) (40mm/s 800N)

Duty cycle:10%,stop for 18 mins after continuoulsy working 2 mins

Ip grade:IP 54

Limit switch:Built-in limit switch,non-adjustable

Operation temperature:+5℃~40℃

Min.install dimension:285mm(175+stroke) [From center of Mounting Holes]

Max.stroke:450mm

Tail connector:90º rotation available

Memory function:optional

Colour:Black/Grey


Timg



Why choose us:

1.100% copper motor. 5. 6000N=600KG=1230LBS Max force 6. 5mm /second=0.2inch/second speed

2. Wiring included, pre-installed,perfect wire cable.

3. Built-in clutch and limited switch prevents over-extending and over-compressing.

4. Aluminum Alloy House material and Aluminum Alloy extend shaft material 10.

5.Steel connector


Warranty

1. If you did not receive product, we will full refund you. 2. If the product had quality problem, we will full refund you. 3. If the product was damaged by shipping company, we will full refund you.

Payment

Paypal,Alipay,Western union or bank transfer.

Shipping

1. All items listed in our store are in stock. Order will be delivered within 2 working days. 2. We use China post air mail but it takes long time. If you want fast delivery, please tell us before ordering and we will select the best shipping method. 3. Please make sure your address and phone is correct. If it is wrong, we do not care any more charge.
















Looking for ideal Linear Actuator For Electric Wheelchair Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the DC Motor For Adjustable Wheelchair are quality guaranteed. We are China Origin Factory of DC Motor For Wheelchair Lift. If you have any question, please feel free to contact us.
